Specification
Model: LL0118UDST
Diameter(inch): D23.6/35.4/47.2"
Diameter(MM): 600/900/1200mm
CCT: 3000K/3500K/4000K
Efficacy: 85lm/w
PF: ≧0.9
CRI: ≧90
Dimming: 0-10V
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: Aluminum, PC
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Pendant
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ ETL listed, 5 years warranty.
◆ 2 color finishes(black, white), can be customized
◆ Quite nice craftsmanship, a beveled regress from the outer profile reveals an evenly illuminated satin lens.
◆ Different colors for the inside bevel and outside frame to match the vibe of your application.
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
LL0118UDST- 60W (up 20w, down 40w) | 60W | D600*175 / D23.6*6.9 | AC120-277V AC220-240V/ | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 85lm/w | white/black | 120*2 | 4FT STEM MOUNTED | Alu+PC |
LL0118UDST-120W (up 48w, down 72w) | 120W | D900*175 / D35.4*6.9 | |||||||||
LL0118UDST-220W (up 88w, down 132w) | 220W | D1200*175 / D47.2*6.9 |
Download
 |
|
|
|
Client Feedback:
"I am putting the samples in the job folder. "
