LL0178-WM
Specification
Model: LL0178-WM
Length(inch): D11.8", 23.6", 35.4", 47.2", 59.1"
Length(mm): D300mm, 600mm, 900mm, 1200mm, 1500mm
CCT: 3000K/3500K/4000K
Efficacy: 70lm/w
PF: ≧0.9
CRI: ≧90
Dimming: non dimmable
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: Acrylic +silicone
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Wall Mounted
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ 5 years warranty.
◆ 3 Tube dia: 1.18"(30mm), 2.0"(50mm), 3.15"(80mm).
◆ Quite nice craftsmanship.
◆ No dark area, soft and even light distribution.
◆ Operation Voltage: AC120-277V, 0-10v dimming and non-dimmable for options.
◆ 360 deg full light emitting.
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
◆ Vertical suspended, horizontal suspended, wall mounted 3 installation style.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
| LL0178-WM-300 | 6W | D300*50 / 11.8*2.0 | AC220-240V / AC120-277V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 70lm/w | White | 360 | Wall Mounted | Acrylic + silicone |
| LL0178-WM-600 | 12W | D600*50 / 23.6*2.0 | |||||||||
| LL0178-WM-900 | 18W | D900*50 / 35.4*2.0 | |||||||||
| LL0178-WM-1200 | 24W | D1200*50 / 47.2*2.0 | |||||||||
| LL0178-WM-1500 | 30W | D1500*50 / 59.1*2.0 |
